How to Remove Pattern Lock Vivo V5 (Vivo 1601)-Password, Pin Remove By SP Flash Tool

How to Remove Pattern Lock Vivo V5 (Vivo 1601), Today we share with you how to remove Password lock Vivo V5 (Vivo 1601) very easily by SP Flash tool. If you have forgotten the pattern lock, Pin code lock, Password code lock of your Vivo V5 (Vivo 1601) Devices. So there we are sharing a simple method to remove the passcode, Pattern lock, Pin code lock with a very simple way, but you may erase all your personal data in this process because we are going to Flashing user data of your Vivo V5 (Vivo 1601) device to remove the password / Pattern lock by SP Flash Tool…


Note: This Method only works for Vivo V5 (Vivo 1601).

Warning: Follow This Method, You will lose all your Private Data.

Download Vivo V5 Pattern Lock File

Download Vivo V5 Pattern Lock File

File Name: –Vivo V5 -1601 Pattern Remove

File Size: -530MB

Tutorial:- Flashing Tutorial

Download-Download USB Driver

Download: –Click Here To Download

Remove Pattern Lock Vivo V5 (Vivo 1601)

-First Download Vivo 1601 Pattern remove to your Computer.

-Then copy and paste the Vivo 1601 Pattern Remove File to your Desktop.

-After that, extract the Vivo 1601 Pattern, Password, Pin Remove file to the desktop.


-Once extracted, open the extracted Vivo 1601 Pattern lock Remove folder.

-There you will see “Pattern Remove File” and “Vivo V5 Flasher Folder“.

-Open the “Vivo V5” Flasher folder.

-After that, Go down and find the “SP Flash tool.exe”.

-Then Run “SP Flash tool.exe“.

-Now, wait to launch the tool.

-Now, Goto “Download” tab.

-After that, click on “Choose” from “Download-Agent“.

-Now give there file path of “Gadgets_Doctor.bin“.

-you can find “Gadgets_Doctor.bin” file from the “Vivo V5_Pattern_Remove” – “Flasher” Folder.

-Then click on “Choose” from “Scatter-loading File

-Now give there file path of “Scatter” file.

-you can find scatter file from the “Vivo V5_Pattrn_Remove” – “Pattern Remove files” folder.

-After that, untick the “Preloader” file. (See Below video Guide)

-Then press “CTRL+ALT+S” on the “SP Flash tool.

-Now you will see extra there are two files tabs will available “Authentication and Certification file” tab.

-After that, click on “Choose” from ” Authentication File“.

-Then, click the “Download” icon on the “SP Flash tool“.

-Now you need to connect your device to Remove Screen Lock Vivo V5 (Vivo 1601).


Remove screen lock Vivo V5 (Vivo 1601)

-First, Power off your Vivo V5.

-After that, Connect your Vivo V5 to PC.

-While connecting press and hold (Volume UP) key, and connect your Vivo 1601.

Note:- Make sure, before you connect your device to PC, you need to download and install USB Driver first on your PC. when you connect your device to PC keep pressing Volume UP key few more seconds after connecting.

-Now you will see a “Redline” will appear on the SP Flash tool.

-After that, a “Yellowline” will be appearing, that’s mean your device is now flashing.

-Wait for finish the flashing to successfully remove Pattern Vivo V5 (Vivo 1601).

-Once flashing finished, disconnect your device to PC.

-After that, Power on your device.

-Once power on your device successfully.

-Setup the initial setup to your device.

-Once setup is done, you need to close the floating window.

-long press on the Chinese “Floating window” icon.

-After that, you will get a popup notification.

-There you will see the option “Closing Floating Window“.

-Tap “OK”.

-Done, now you have successfully Remove Pattern Lock Vivo V5 (Vivo 1601).

Video Guide:

Subscribe Our Channel For More Interesting Videos Daily (On Youtube):-SUBSCRIBE

Thanks for visiting us, Comment below if you face any problem With Remove Pattern Lock Vivo V5 (Vivo 1601), we will try to solve your problem as soon as possible. you can check other some tutorial here to help you.
